CircuitDiagramMaker
One browser workspace from schematic to handoff
CircuitDiagramMaker is a browser workspace for electrical designs that must stay connected beyond the drawing. Build schematics and wiring diagrams, then carry the same structured project into breadboard, PCB Lite, 2D/3D control panels, harnesses, live schedules, review and releases. Includes 482 symbols, 2,278 editable diagram references, supported-model simulation, offline recovery, and PNG, SVG, PDF, DXF, SPICE and CSV outputs. Start drawing without an account.
Hey Product Hunt — Paul here 👋
I built CircuitDiagramMaker because an electrical drawing is only the beginning of the job. The same components and connections often have to be recreated across a schematic, prototype, panel layout, cable schedule, bill of materials and final handoff. Every duplicate introduces drift.
CircuitDiagramMaker keeps that work in one structured browser project:
• Draw schematics and wiring with automatic routing and net tracking
• Carry the same design into breadboard, PCB Lite, and 2D/3D control-panel views
• Generate live device, wire, cable, terminal, load, PLC I/O and BOM reports
• Run supported DC, transient, AC, and control-circuit simulations
• Review changes, preserve releases, and export PNG, SVG, PDF, DXF, SPICE and CSV
• Start as a guest with local recovery—no account or installation required
The library currently includes 482 electrical symbols and 2,278 editable diagram references. Every new account receives a 14-day Pro trial without a card, then returns to Free unless the user explicitly subscribes.
I have tried to be equally clear about the boundaries: this is not a claim to replace native DWG workflows, plant-scale catalogues, production PCB DFM, arbitrary SPICE models, or professional engineering sign-off. It is built for accessible, connected electrical documentation and handoff.
I would especially value feedback from electrical designers, controls engineers, technicians, makers and educators:
1. Where does your handoff break today?
2. Which physical workspace or report should we deepen next?
3. Which symbol or starter template is still missing?
Thanks for taking a look. I’ll be here throughout launch day and will reply to every question.
