BalloonPlot
AI drawing ballooning & AS9102 FAI reports in seconds
Automate engineering drawing ballooning, extract GD&T tolerances, and generate AS9102 Rev C Form 3 inspection sheets in seconds with BalloonPlot and inspection documentation for quality engineers, aerospace suppliers, and machine shops. Drop any PDF engineering drawing to automatically detect dimensions, extract ASME Y14.5 GD&T feature control frames, and export production-ready AS9102 Rev C Form 1, 2, and 3 Excel inspection sheets and stamped PDF packages in under 30 seconds.
Hey Product Hunt community! 👋
I'm excited to share BalloonPlot with you today.
For quality inspectors, machine shop owners, and aerospace engineers, "drawing ballooning" (manually stamping numbered bubbles next to hundreds of drawing dimensions with red pens or PDF editors) is a tedious, error-prone bottleneck that can take 1–2 hours per blueprint.
We built BalloonPlot to solve this with precision computer vision:
🚀 Drop any PDF blueprint or CAD drawing
🔍 Automatic detection of linear dimensions, notes, and ASME Y14.5 GD&T feature control frames
📊 1-click export to production-ready AS9102 Rev C Form 1, 2, & 3 Excel inspection sheets and stamped PDFs
⏱️ Cuts a 90-minute manual task down to under 30 seconds
Try it out free at https://balloonplot.com/ (no credit card required).
We’d love to hear your thoughts, feedback, and feature requests from anyone working in engineering, CAD, or hardware manufacturing!
